How does it work?
Palette 2 takes up to four filaments and combines them into a single filament strand. This strand is then fed to your printer, enabling your single-extruder printer to create multi-filament prints!
Drive: Palette 2’s all-metal drive systems, inspired by those on industrial FDM machines, accurately control filament to ensure the right lengths are driven from each input.
Cut: A rotary cutter system slices filament to ensure a clean, low-resistance cut, time after time.
Connect: Palette 2’s updated Splice Core connects filaments together end-to-end before passing them through a machined PTFE (Teflon) channel and splicing them together.
Cool: The newly spliced filament is passed to our buffer are to cool and ensure that it keeps tight dimensions before being passed to your printer.
Calibrate: There’s no need to attach our Scroll Wheel to your printer anymore as it is now built inside of Palette 2, allowing for more precise calibration and a streamlined Palette experience.
Take your Palette 2 experience farther with improved features and functionality
For high-demand printers and workhorse makers, we offer the Palette 2 Pro.
Palette 2 Pro includes:
All aluminum Splice Core Pro allows for faster splicing and cooling, improving the overall print time
Includes additional parts to ensure optimal performance and maintenance
Sleek all-black casing
Extended 1-year warranty
Take your Palette 2 experience farther with improved features and functionality
For high-demand printers and workhorse makers, we offer the Palette 2 Pro.
Palette 2 Pro includes:
All aluminum Splice Core Pro allows for faster splicing and cooling, improving the overall print time
Includes additional parts to ensure optimal performance and maintenance
Sleek all-black casing
Extended 1-year warranty
Other Features
Splice Core |
CANVAS Hub |
|
Palette 2’s improved splice mechanism creates stronger and more reliable bonds between filament. |
Simplify and enhance the entire printing process by wirelessly connecting your printer, Palette 2, and computer using CANVAS Hub (sold separately). |
Multi-Material Combinations
Multi-Color |
Soluble |
|
Several multi-color models printed in PLA. |
Spaceship printed with Palette 2 using supports. |
Durable |
Flexible |
|
Multi-color guitar picks printed in PETG for durability. |
Watch bands made from flexible TPU. Files: http://mm3d.co/watch-band. |
FAQ
Q: Does Palette 2 work with 2.85mm or 3mm filament?
A: Sorry, no! Palette 2 only works with 1.75mm filament.
Q: What materials does Palette 2 work with?
A: Palette 2 supports several combinations of materials. A full list can be found on the Palette 2 multi-material printing guide at http://mm3d.co/multi-material.
Q: How do Palette 2 and the printer know which color is which?
A: Each color/material is a separate model. If you’re printing in 4 colors/materials, you will need 4 different model files. You can find models at http://mm3d.co/stuff-to-print or learn how to split 1 STL into multiple models at http://mm3d.co/meshmixer. The model is sliced as a multi-body G-code file. The G-code file is processed in Mosaic Chroma (free, easy-to-use software) or CANVAS (our web-based slicer/customizer/modifier) to create a new files for the printer Palette 2 with instructions on when to switch between filaments.
Q: Any software requirements?
A: Mosaic CANVAS software (free at https://canvas3d.io) or Chroma software (free software that accepts G-code and tells Palette 2 how much of each filament is required) works on Windows (7, 8, 10 or higher, 32-bit and 64-bit), macOS (Mountain Lion/10.8 or newer), and Linux (x64, tested on Ubuntu 16.04).
