Seeed Studio

A red laser with a line shape

COM-00139
In Stock
R85.00
Tax included
7 Items

  Secure Checkout

Pay via Card, Zapper or Bank Transfer.

  Free Delivery over R1000

To your door delivery. South Africa Only.

  Guaranteed Customer Support

Need help? See our Support Page.

custom html

Description

A red laser with a line shape.

Specifications:
  • Output Power: Min 2.5mW, Typical 3.0mW, Max 5.0mW
  • Working current: Min 10mA, Typical 20mA, Max 25mA
  • Working voltage: Min 2.3VDC, Typical 4.5VDC, Max 8.0VDC
  • Wavelength: 650nm
  • Working Temperature: Min -15°C, Typical 25°C, Max 35°C
  • Storage Temperature: Min -20°C, Max +25°C
  • Focused Dot width:
  • Practical test for point head: reflection visible to random target >1000m
Warning: Class III, avoid direct eye exposure to beams.

Documentation:
