RS232 to RS485 Converter (DB9 Connector)
RS232 to RS485 Converter (DB9 Connector)

RS232 to RS485 Converter (DB9 Connector)

This is a standard RS232 to RS485 Converter that has DB9 on RS232 side and Screw terminals for RS485
INT-00098
In Stock
R75.60
Tax included

  Secure Checkout

Pay via Card, Zapper or Bank Transfer.

  Free Delivery over R750

To your door delivery. Main Centres Only.

  Guaranteed Customer Support

Need help? See our Support Page.

Description

Description:

This is the go-to converter for signal conversion.
This Converter allows you to seemlessly converter your signal for RS485 to RS232 and vice versa.

The RS232 side of this connector is a standard female DB9 connector.
The RS485 side exists as 4 screw terminals.(485+, 485-,GND, 5 - 12V)

Specifications:

- Compatibility: EIA/TIA RS232C standard and RS485 standard
- Interface RS232 side: DB9 female connector.
- Interface RS485 side: 4 screw terminals
- Transmission rate: 300 - 115200bps
- Transmission distance: RS485 max. 1200m, RS232 side max. 5m
- Working mode: asynchronous, half-duplex, differential transmission.
- Working environment: -20 ~ 70°C, relative humidity 5% - 95%
- Mechanical dimensions: 95mm x 33mm x 17mm

Documentation:

User Guide
